• CONSTRUCTION

Housing:
FER1-03LB: Aluminum with corrosion resistant black finish
UFExHD2-B Series: Steel with corrosion resistant black finish

Front Cover: High-impact thermoplastic, UL94V-0 fire-retardant
Grommets: Rubber

  • CAPACITY

FER1-03LB:
Adapter Plates/ Cassettes: 3 Max
Splice Trays: 3 Max
UFE6HD2-B:
Adapter Plates/ Cassettes: 6 Max
Splice Trays: 4 Max
UFE12HD2-B:
Adapter Plates/ Cassettes: 12 Max
Splice Trays: 8 Max
Compatible with FST-XA & FST-XF splice trays

  • DIMENSIONS

Width: 19.0” (482.6 mm) EIA/ECA-310-E standard
Depth:
FER1-03LB: 16″
UFE6HD2-B: 14″
UFE12HD2-B: 14″
Height:
FER1-03LB: 1 RMU (1.75” (44.45 mm))
UFE6HD2-B: 2 RMU (3.50” (88.90 mm))
UFE12HD2-B: 4 RMU (7.00” (177.80 mm))

  • ENVIRONMENTAL CONDITIONS

Operating Temperature: 14 °F to 140 °F (-10 °C to 60 °C)
Storage Temperature: -40 °F to 158 °F (-40 °C to 70 °C)
Operating RH: 93% Max (non-condensing)

  • WARRANTY

5-year limited component warranty
10-year Signamax Link/Channel Warranty
15-year Signamax Extended Component Warranty
25-year Signamax Cabling System Warranty
